Original high-resolution panchromatic band multispectral Micasense camera Rededge-P
- • RedEdge-P Sensor
- • Lens cover
- • Calibrated reflectance panel
- • Built-in GPS DLS 2 optical sensor
- • RedEdge-P and DLS 2 cables
- ・Installation screw
- • Hard carrying case
- • CFexpress card reader
| Product Description |
|
Michael Sense Camera Rededge-P ► New standards for data quality and reproducibility
RedEdge-P uses dedicated optics and industry-leading industrial imaging
It combines sensors with science-grade narrowband filters. Furthermore, it is
High quality through strict factory calibration process
A robust, calibrated tool that delivers reliable, pan-sharp, multispectral output.
|
|
| ► application | |
|
• Count the number of plants.
• Phenotypic analysis • Map plant health status • Fertilizer management • Identifying illness
|
• Species identification and weed detection.
|
|
Seasonal Canopy Analysis with Higher Resolution
RedEdge-P is reliable, robust, high quality, powerful with high resolution panchromatic bands that provide pan-sharp output resolution of 2cm (at 60m) twice the industry's terrestrial resolution. It is a multispectral sensor. The RedEdge-MX offers comprehensive seasonal capabilities, allowing pixel-adjusted output at previously unattainable resolutions, while maintaining the efficiency and reliability of traditional RedEdges. Tree canopy analysis of plants at all stages of growth.
Fly lower. It flies faster. See more.
RedEdge-P uses professional grade CFexpress memory card standards, Removable storage in a customizable size ranging from 64 GB to 2 terabytes. All image bands can be captured continuously for more than 24 hours per second. for For jobs that require multiple flights, there is no need to connect cables to the camera for each flight. Fly or bring your computer to the site. RedEdge-P Removable Storage The next flight began within seconds.
Main featuresIncreased storage HIGH-RES RGB and multispectral synchronous capture Double the spatial resolution of previous RedEdge Working with what you have (drones, processing, flight planning) Sturdy design
|
| Product Specifications |
| Weight | 350g (12.3oz) (RedEdge-P DLS 2) |
| size | 8.9 x 7.0 x 6.7cm (3.5" x 2.8" x 2.6") |
| External power supply | 7.0V to 25.2V |
| Power input | 5.5/7.0/10W (Standby, Average, Peak) |
| Sensor resolution | 1456 x 1088 (1.6MP per MS band) 2464 x 2056 (5.1MP Punk Band) |
| Spectrum Band | Blue, green, red, red edge, near infrared (Global shutter, narrow band) |
| Wavelength (nm) | Blue (center 475 nm, bandwidth 32 nm), Green (center 560 nm, bandwidth 27 nm), Red (center 668 nm, bandwidth 14 nm); Red edge (center 717 nm, bandwidth 12 nm), Near-infrared (center 842nm, bandwidth 57nm) |
| RGB color output | 5.1 MP (Global shutter, adjustable to all bands) *If appropriate post-processing is performed |
| Ground Sample Distance (GSD) | 120m (approx. 400 ft) AGL 7.7 cm per pixel (per MS band) 120m (approx. 400 ft) AGL at 3.98 cm per pixel (Panchromatic band) |
| Capture rate | Up to 3 raw DNG captures per second |
| interface | Choose from three configurable GPIOs (trigger-in, PPS-in, PPS-out, and top-of-frame signals). Host virtual button. USB 2.0 port for WiFi. serial. 10/100/1000 Ethernet. CF Express for storage |
| Field of view | 50° HFOV x 38° VFOV (MS) 44° HFOV x 38° VFOV (PAN) |
| Storage | CFexpress Card |
