Precise, effective locating and tracing

Speed, accuracy and reliable performance

Easy to setup and use

Sun light readable display, high performance audio system and vibration alerts for noisy environments

Sensitive and accurate signal processing for reliable results

Multi-function multi-industry accurate locating

Compass Orientation

Power filters

Utility specific frequencies

Protecting technicians and infrastructures

Encourage correct locator handling for improved detection

StrikeAlert, warns of the presence of shallow cables

Vibration handle, never miss a warning

Ergonomic design, premium quality

Rugged yet light weight and ergonomic

Designed and built to the highest standards in Great Britain

Self Test for confidence and trust in your locator measurements

Multi-function multi-industry locating

Construction

Accurate and simple to use, the RD7200 comes with eight active and three passive frequencies that cover the majority of site locating tasks. A rugged, IP65 rated casing along with a high contrast screen make it suitable for use in all weather conditions.

Power

In complex power environments, with multiple signals from high voltage equipment and cables, Radiodetection’s Dynamic Overload Protection reduces the effect of interference and Power Filters can be used to trace a single target line amongst multiple cables.

Water and Pipeline

A wide choice of active frequencies allow conductive pipes to be traced for long distances. Where sondes or cameras are used to survey pipes made from a variety of materials (including cast iron, clay, fiber, concrete and brick) the four RD7200 sonde frequencies are ideal for quickly locating and tracing their position. Pipes with Cathodic Protection System can be followed using the CPS passive mode. CPS compass mode ensures alignment with the target pipeline.

Telecom

Telecom The RD7200 features higher frequencies to locate high impedance lines and sonde frequencies for duct and conduit tracing. Higher frequencies can also be used to trace sheathed domestic cables without grounding connections. Cable sheath faults can be located to within 4" (10cm) using 8kHz Fault Find mode with a Radiodetection A-Frame.

Ordering information

✔ Available, enabled by default      ●Option      ■ Available, disabled by default.
